METAL SHAFT TYPE VOLUME 10mm


102L-NR
■10mm diameter.
■Total rotational angle:220゜
■Printed board terminal
■Rotational life: 500,000 cycles.
■Total resistance: 5KΩ

Applications: servomechanism of robot and radio controllers.
図面


METAL SHAFT TYPE VOLUME 13mm


132L-NR
■13mm size, single unit.
■Rotational angle: 220゜
■Long life VR(500,000cycles)
■Applications: servomechanism of robot and radio controllers.
■Long Shaft is also available (7.5, 15mm)
図面


METAL SHAFT TYPE VOLUME 17mm


171P-S2R
■17mm size, single unit.
■Swich: SPST 12V. 1A(171P-S2R).
■Rotational angle: 220゜
■Long life VR(300,000cycles)is also available(171L-NR).
171L-NR is suitable for radio controlled models.
図面



1712-RS1R
■17mm size, single unit.
■Switch :SPST DC12V, 3A
 (1712-SER)
 SPST AC120V, 1A(1712-RS1R)
 SPST AC120V, 3A(1712-RS3R)
■Rotational angle: 300゜
■With P.C.Board terminals are also available.
■Center Tap(1712T5-NR)
 40% Tap(1712T4-NR)
 60% Tap(1712T6-NR)
 Center click(1712PC-NR)
 11 detents(1712PC11-NR)
 21 detents(1712PC21-NR)
図面



1712P-RS3R
■17mm size, single unit.
■Switch :SPST DC12V, 3A
 (1712-SER)
 SPST AC120V, 1A(1712-RS1R)
 SPST AC120V, 3A(1712-RS3R)
■Rotational angle: 300゜
■With P.C.Board terminals are also available.
■Center Tap(1712T5-NR)
 40% Tap(1712T4-NR)
 60% Tap(1712T6-NR)
 Center click(1712PC-NR)
 11 detents(1712PC11-NR)
 21 detents(1712PC21-NR)

Applications: light controll unite, electrical blanket,and etc.
図面


METAL SHAFT TYPE VOLUME 24mm


247-8SER
■24mm size, single unit.
■With P.C.Board terminals are also available.
■Switch:247-8SER
 SPST AC125V, 1A
 247-8SFR SPST AC125V, 3A
 247-3SFR SPST AC125V, 3A
■Rotational angle: 300
図面


METAL SHAFT


METAL SHAFT

Although shaft size can be catered to your need,
we want you to choose the standard size of the
right table.

METAL SHAFT
